Technical description:

• Mass:37.2kg
• Size: 710 mm
• Surface of rotor: Coated in black
• Material of terminal box: Die-cast aluminium
• Material of blades:Press-fitted sheet steel blank, sprayed with PP plastic
• Material of guard grille: Steel, phosphated and coated in black plastic
• Type of protection: IP 54
• Insulation class: "B"
• Max. temperature: + 80 °C
• Min. temperature: - 40 °C
• Motor bearing: Ball bearing

  ---

Nominal data:

• Phase: 3~
• Type of voltage: AC
• Nominal voltage in V: 400
• Frequency in Hz: 50
• Type of data definition: max. load
• Air flow m3/h: 10730
• Speed rpm: 905
• Power imput in W: 1030
• Current draw in A: 2.35
• Max. back pressure in Pa: 125
• Min. ambient temperature in°C: -40
• Max. ambient temperature in°C: 80
