Range of centrifugal roof mounted fans in horizontal discharge format, designed for smoke extraction in fire conditions and certified F400-120. THREE-PHASE 4 POLE MOTORS
Supply (V): 230-400
Speed (rpm): 1400
Maximum absorbed power (W): 163
Maximum absorbed current (A-230V): 0.5
Maximum absorbed current (A-400V): 0.3
Maximum air volume (m³/h): 1210
Sound pressure level (dB(A)) inlet: 51
Sound pressure level (dB(A)) outlet: 55
Weight (kg): 18.8
Dimensions (mm):
AH = 570
BH = 382
C = 435
D = 261
E = 300
F = 12
G = 40
Roof ventilator CTHT/4-225
- Cod Produs: CTHT/4-225
- Disponibilitate: In Stoc
-
3,088.07ron
- Fara TVA: 2,552.12ron
